主要用途：
1. 銅面基板 2. 絕緣板 3. 矽膠絕緣導熱片 4. 防火布 5. 絕緣布 6. 工程塑膠補強
特性與規格：
|
型號 |
紗種規格 |
密度 |
基重 |
厚度 |
||
|
經向 |
緯向 |
經向 |
緯向 |
|||
+/-2 Ends/In. |
(g/m2) |
(mm) |
||||
|
TGFC-7196
|
ECG-67 1/0 |
ECG-67 1/0 |
44 |
36 |
233±3.0 |
0.193±0.020 |
|
TGFC-7628U
|
ECG-67 1/0 |
ECG-67 1/0 |
42 |
34 |
220±3.0 |
0.183±0.020 |
|
TGFC-7628M
|
ECG-75 1/0 |
ECG-75 1/0 |
44 |
33 |
210±3.0 |
0.175±0.020 |
|
TGFC-7628L
|
ECG-75 1/0 |
ECG-75 1/0 |
44 |
31 |
202±3.0 |
0.173±0.020 |
|
TGFC-1506
|
ECE-110 1/0 |
ECE-110 1/0 |
46 |
45 |
165±2.5 |
0.140±0.015 |
|
TGFC-1500
|
ECE-110 1/0 |
ECE-110 1/0 |
49 |
42 |
164±2.5 |
0.149±0.015 |
|
TGFC-2166
|
ECE-225 1/0 |
ECG-75 1/0 |
60 |
38 |
155±2.5 |
0.145±0.015 |
|
TGFC-2157
|
ECE-225 1/0 |
ECG-75 1/0 |
60 |
35 |
148±2.5 |
0.140±0.020 |
|
TGFC-1504
|
ECDE-150 1/0 |
ECDE-150 1/0 |
60 |
50 |
148±2.5 |
0.135±0.015 |
TGFC- 1652 |
ECG-150 1/0 |
ECG-150 1/0 |
52 |
52 |
138±2.5 |
0.114±0.015 |
|
TGFC-2165
|
ECE-225 1/0 |
ECG-150 1/0 |
60 |
48 |
120±2.5 |
0.101±0.015 |
|
TGFC-2116H
|
ECE-225 1/0 |
ECE-225 1/0 |
60 |
59 |
106±2.0 |
0.094±0.015 |
|
TGFC-2116
|
ECE-225 1/0 |
ECE-225 1/0 |
60 |
57 |
104±2.0 |
0.094±0.015 |
TGFC-3313 |
ECDE-300 1/0 |
ECDE-300 1/0 |
60 |
62 |
81±2.0 |
0.084±0.010 |
TGFC-2313 |
ECE-225 1/0 |
ECD-450 1/0 |
60 |
64 |
81±2.0 |
0.084±0.010 |
TGFC-2113 |
ECE-225 1/0 |
ECD-450 1/0 |
60 |
56 |
78±2.0 |
0.079±0.010 |
TGFC-2112 |
ECE-225 1/0 |
ECE-225 1/0 |
40 |
39 |
69±2.0 |
0.081±0.010 |
TGFC-1080 |
ECD-450 1/0 |
ECD-450 1/0 |
60 |
47 |
47±2.0 |
0.053±0.010 |
TGFC-1280 |
ECD-450 1/0 |
ECD-450 1/0 |
60 |
60 |
53±2.0 |
0.051±0.010 |
TGFC-1078 |
ECD-450 1/0 |
ECD-450 1/0 |
54 |
54 |
47.8±2.0 |
0.043±0.010 |
TGFC-1067 |
ECD-900 1/0 |
ECD-900 1/0 |
70 |
68 |
30.2±1.5 |
0.035±0.005 |
TGFC-106 |
ECD-900 1/0 |
ECD-900 1/0 |
56 |
56 |
24.4±1.5 |
0.033±0.005 |
